Product advantages:
- Metrological high precision: With a measurement accuracy of ± 0.05%FS, it meets the requirements of trade handover and reduces metrological disputes
- Multi-parameter synchronous measurement: Simultaneously output liquid level, interface, and temperature parameters, providing comprehensive process information
- Fully contactless measurement: Magnetic coupling non-contact measurement, no mechanical wear, long service life
- Wide temperature range application: Operating range from -196℃ to +200℃, suitable for various working conditions from deep cold to high temperature
- Intelligent self-diagnosis: Real-time monitoring of float status and waveguide health, and early warning of potential faults
- Maintenance-free design: One-time installation, long-term maintenance-free, significantly reducing life cycle costs
Core application fields:
- Petrochemical industry: Trade handover measurement of crude oil storage tanks and finished oil tanks (conforming to API standards
- LNG storage and transportation field: precise liquid level measurement of liquefied natural gas storage tanks (-196℃ cryogenic conditions)
- Chemical production process: liquid level and interface control of reaction vessels and separators
- Food and pharmaceutical industry: process liquid level monitoring of high-purity media
- Energy and power system: measurement of water level in high-pressure boiler drum
Technical Specifications:
- Range(mm): 0.2m~25m
- Medium density (g/cm3): ≥0.45
- Medium viscosity: ≤0.02Pa.S
- Working temperature(℃): -180~350
- Pressure levels (MPa): ≤32
- Measurement accuracy (mm): ≤+10
- Installation: Side-mounted, roof-mounted, bottom-mounted
- Protection: IP65
- Proof grade: ibⅡCT4 (intrinsically safe), dⅡBT3 (flameproof)
- Transmission: 4 ~ 20mA or switch
- Power supply: 12~24 V DC
- Temperature drift: 50 ppm/℃
- Insulation resistance: 50 V,50MΩ
- Explosion-proof: ExdⅡCT6Gb
