Deskripsi
Product advantages:
- High-precision measurement: Utilizing radar technology, the measurement error is low, ensuring the accuracy of the data.
- Strong anti-interference ability: It can operate stably in high-temperature, high-pressure and steam environments, and adapt to various harsh conditions.
- Low maintenance cost: With no moving parts, it reduces maintenance frequency and cost.
- Easy installation: It can adapt to various installation methods and is suitable for different industrial scenarios.
- Real-time Monitoring: Supports remote data transmission, facilitating real-time monitoring and management.
Application field:
- Oil and gas: used for liquid level monitoring in oil tanks, natural gas storage, etc.
- Chemical industry: Monitoring liquid level changes in equipment such as reaction vessels and storage tanks.
- Water treatment: used for liquid level control in fields such as sewage treatment and drinking water storage.
- Food and beverages: Precise measurement of liquid levels in fermentation tanks and storage tanks.
- Pharmaceutical industry: used for monitoring liquids in the drug production process.
Technical Specifications:
- Frequency: 500MHz-1.8GHz
- Application range: Liquid and solid powder measure,complicated process conditions
- Measuring range: 20 m
- Power Source: Two-wire(DC24V),Four-wire (DC24V/AC220V)
- Signal output: 4~20mA/HART(two-wire/four-wire) RS485/Modbus
- Process connection: Flange, thread
- Medium temperature: -40℃~250℃
- Process pressure: -0.1~2MPa
- Measurement accuracy: ±10mm
- IP rating: IP67
- Explosion-proof grade: Exia IIC T6 Ga /Exd ia IIC T6 Gb
- Shell material: aluminum casting/stainless steel
