Product advantages:
- Wide range of applicable media: It can measure various materials such as liquids, slurries, powders, and particles, with a broad range of applications
- High pressure and high temperature resistance: With a special structural design, it can withstand a maximum pressure of up to 25 mpa and a temperature of up to 400℃
- Strong anti-interference ability: It is not affected by changes in medium density, bubbles or pressure, ensuring stable and reliable measurement
- Simple and convenient installation: Compact structure, only one installation hole needs to be made on the container, making installation and maintenance simple and convenient
- No moving parts: Based on the static measurement principle, it has no wearing parts and a long service life
- Economical and practical: Compared with other level gauges, it offers high cost performance and low maintenance costs
Core application fields:
- Petrochemical industry: liquid level measurement of various corrosive media such as acids, alkalis and solvents
- Power and energy field: boiler drum water level measurement, deaerator water level monitoring
- Water treatment environmental protection: liquid level control of sewage tanks, sludge tanks, and chemical agent tanks
- Food and pharmaceutical industry: liquid level detection of viscous media such as sauces, syrups, and raw materials for medicines
- Metallurgical and mining industry: level measurement of granular solids such as pulp, fly ash, and cement
Technical Specifications:
- Application: Liquid, oil, water
- Measuring range: 300-3000mm
- Process connection: M20*1.5Thread,flange
- Power Supply: 24VDC
- Output Signal: 4-20mA
- Compensation temperature: -10~70°C
- Media temperature: -30~150°C
- Store temperature: 20~80°C
- IP grade: IP65
- Explosion-proof grade: ExiaIIC T6 Ga/ExiaIC T6 Gb
- Accuracy: 0.5%FS ,0.25%FS( Need customized)
- Work pressure: 0.6-3Mpa
